Chapter 6 Normal Mode
66
6
I I I I I Area Check Function
When the number of edges changes during measurement, the area check function
displays the “----” error message. It also cancels the measured value by detecting
the difference from the preset total number of edges.
■ Effective Application
When dust or oil adheres to the scanning head or no target is placed in the
measuring area, the area check function prevents an abnormal measured value
from being displayed or output.
■ Setting Procedure
1. Select the OPTIONS screen.
Press the [OPTIONS] button.
2. Select the UTILITY screen.
Press the [UTILITY] button.
3. Press the [AREA CHECK] button.
4. Set the number of edges.
Press the [SET] button.
Enter a value using the numeric keys.
Press the [OFF] button to turn it ON.
Every time you press the button, the display toggles between [ON] and [OFF].
LASER ON OPTIONS NOR
MAL P. 1
DISPLAY
DATA
LIMIT
SETUP PROGRAM CALIB OPTIONS
AREA
OUTPUT
INSPECT
UTILITY
Select Option to setup.
MODE
CHANGE
Normal
-> Pitch
LASER ON UTILITY NOR
MAL
P. 1
AREA CHECK
INITIALIZE
ON
PANEL
mm
ONE-SCAN MODE
PROGRAM SELECT
DISPLAY UNIT
ESC
LASER ON AREA CHECK NOR
MAL
P. 1
OFF
ESC
SET
HEAD No.
HEAD1 A1
NO. OF
EDGES
( 4 )
DIA
SEGMENT
OFF SET
HEAD No.
HEAD1 A2
NO. OF
EDGES
( 4 )
DIA
SEGMENT
SEGMENT
SEGMENT
OFF SET
HEAD No.
HEAD1 A3
NO. OF
EDGES
( 4 )
DIA
OFF SET
HEAD No.
HEAD1 A4
NO. OF
EDGES
( 4 )
DIA
