Appendices
116
Appendices
Appendix B Initial Settings
NORMAL Mode
Item Initial setting
Display Data Display output OUT1 ON
OUT2 OFF
OUT3 OFF
OUT4 OFF
Display Graph Display Graph OUT1
Display output Upper Limit 40 mm (1.57 inch)
Lower Limit 0 mm (0 inch)
Time Sampling Frequency 1
No. of Data 100
Limit Setup 1. HI3 90.0000 mm (4.00000 inch)
HI2 80.0000 mm (3.00000 inch)
HI1 40.0000 mm (1.57000 inch)
LO1 0.0000 mm (0.00000 inch)
LO2 -80.0000 mm (-0.80000 inch)
LO3 -90.0000 mm (-0.90000 inch)
Program No. 1
Options Area Setup 2. Head No. 1
Area DIA
Output Mode 3. Calculation 4. Area 1 Area 2 Area 3 Area 4
+A1 OFF OFF OFF
No. of averaging 768
measurements
M. Mode Normal
Self-Timing Interval (ms) 100
Digit Suppress None
Offset 0.0000 mm (0 inch)
Analog Output +10 V 40 mm (1.57 inch)
-10 V 0 mm (0 inch)
Utility One-Scan Function OFF
Program Select Panel
Display Unit mm
Area Setup No. of Edges 4
ON/OFF OFF
1. Indicates initial settings for all differentiation outputs (OUT1 to OUT4).
2. Indicates initial settings for all areas (A1 to A4).
3. Initial settings for all outputs (OUT1 to OUT4) (except for “Calculation”).
4. Initial setting for OUT 1.
Initial settings for OUT2 to OUT4 are as follows:
Area 1 Area 2 Area 3 Area 4
OUT2 OFF +A2 OFF OFF
OUT3 OFF OFF +A3 OFF
OUT4 OFF OFF OFF +A4
