Chapter 6 Normal Mode
60
6
E E E E E Inspection
The scanning head can be checked for conditions such as dust on the front
surface, laser condition, and optical axis alignment.
■ Setting Procedure
1. Select the OPTIONS screen. Press the [OPTIONS] button.
2. Select the INSPECT screen. Press the [INSPECT] button.
3. Check the condition of the scanning head.
Press the button corresponding to the scanning head to be inspected.
When the condition of the scanning head is normal, the display is as shown
below.
Note 1: During the scanning head inspection, measurement is interrupted. (The
comparator output and analog output are the same as when “-----” is displayed.)
Comparator output: All outputs are OFF.
Analog output: Retained at +10 V.
Note 2: When any problem occurs with the laser diode, the message “LASER” is
displayed on the screen.
OPTIONS OUTPUT OUT1 • • • OUT4
LASER ON OPTIONS NOR
MAL P. 1
DISPLAY
DATA
LIMIT
SETUP PROGRAM CALIB OPTIONS
AREA
OUTPUT
INSPECT
UTILITY
Select Option to setup.
MODE
CHANGE
Normal
-> Pitch
LASER ON INSPECT NOR
MAL
P. 1
HEAD1
HEAD2
HEAD3
HEAD4
ESC
Select Head to inspect.
INSPECT HEAD1 LASER ON P. 1
BEAM INTENSITY
HEAD R
: OK
: OK OPTICAL AXIS
ESC
NOR
MAL
