Chapter 7 Pitch Mode
74
7
■ Setting Procedure
1. Select the DISPLAY DATA screen.
Press the [DISPLAY DATA] button.
Press the [SCREEN] button.
2. Select the data display screen.
Press the button corresponding to the output to be displayed to turn it ON.
Press the [ESC] button.
3. The screen has been changed.
LASER ON DISPLAY DATA PITCH P. 1
HEAD1 OK
Max 0.5010
Min 0.4990
HEAD2 OK
Max 0.6010
Min 0.5990
SCREEN
DISPLAY
DATA
LIMIT
SETUP PROGRAM OPTIONS
LASER ON DISPLAY SETUP P. 1
ON HEAD1
ON HEAD2
ON HEAD3
ON HEAD4 ESC
Set Output to display data.
PITCH
LASER ON DISPLAY DATA PITCH P. 1
HEAD1
OK
Max
Min
0.5010
0.4990
HEAD2
OK
Max
Min
0.6010
0.5990
HEAD3
OK
Max
Min
0.7020
0.6980
HEAD4
OK
Max
Min
0.8020
0.7980
SCREEN
DISPLAY
DATA
LIMIT
SETUP PROGRAM OPTIONS
