Appendices
114
Appendices
Appendix A Specifications
Specifications
Controller
Type Built-in Display type Separate display type
Model LS-5501 LS-5001
Display Measured value display Liquid crystal display, 320 x 240 dots, Backlit —
Min. Display units 0.05 µm —
Display range -99.99995 to 999.99995 —
Measuring range mm/inch selectable —
Comparator output indicator 7-level, Liquid crystal display —
Laser ON alarm indicator Liquid crystal display —
(Scanning head: Green LED)
Terminal Program select input Non-voltage input (contact / solid state)
block input Laser remote input
Interface RS-232C output Measurement data output and control input
I/O board 1. Timing input,
Hold reset input,
Non-voltage input (contact / solid state)
Auto-zero /
Auto-zero reset input
Analog output ±10 V output
7-level comparator output NPN open-collector output 100 mA (40 V) max.
Power supply voltage 85 to 264 VAC, 50/60 Hz 24 VDC ±10%, Ripple (P-P) 10% max.
Current consumption 8.5 A max. 1.4 A max.
Ambient temperature 0 to 45°C (32 to 113°F), No condensation
Relative humidity 35 to 85%, No condensation
Weight Approx. 3.7 kg Approx. 1.1 kg
1. The I/O board is available as an option.
Scanning Head
Type Standard Wide range
Scanning head type Separate
Model LS-5041 LS-5121
Measuring range 0.2 to 40 mm 0.8 to 120 mm
Smallest detectable object 0.2 mm 0.8 mm
T-to-R distance 160 ±40 mm 400 ± 100 mm, 1000 mm max. 1.
Light source Visible red semiconductor laser
Wavelength 655 nm 655 nm
Output FDA (CDRH) Part 1040.10 0.8 mW 45 µW
IEC60825-1 130 µW 45 µW
Pulse duration 63 µs 14 µs
Laser FDA (CDRH) Part 1040.10 Class II
Class IEC60825-1 Class 2
Measuring accuracy ±2 µm max. 2. ±8 µm max. 3.
Repeatability ±0.3 µm max. 4. ±1 µm max. 5.
Laser scan rate 1200 scans/sec.
Laser scan velocity 121 m/sec. 504 m/sec.
Laser scan range Approx. 46 mm Approx. 124 mm
Enclosure rating IP64 IP65
Ambient temperature 0 to 50°C (32 to 112°F), No condensation
Relative humidity 35 to 85%, No condensation
Weight (including base) Approx. 1.4 kg Approx. 5.5 kg
1. When the transmitter-to-receiver distance is set to 1,000 mm, the measurable area is limited to within 800 mm of the tramsmitter.
2. When a rod 10 mm in diameter is measured in a 10 x 20 mm measurement area, the center of which is 80 mm from the transmitter.
3. When a rod 40 mm in diameter is measured in a 40 x 80 mm measurement area, the center of which is 200 mm from the transmitter.
4. When an object is measured in a 10 x 20 mm measurement area, the center of which is 80 mm from the transmitter, with the number of
averaging measurements set to 768.
5. When an object is measured in a 40 x 80 mm measurement area, the center of which is 200 mm from the transmitter, with the number of
averaging measurements set to 768.
