Chapter 7 Pitch Mode
81
7
7 7 7 7 7 Measuring Mode
The LS-5000 series provides the following three measuring modes.
LASER ON OPTIONS P. 1 PITCH
DISPLAY
DATA
LIMIT
SETUP PROGRAM OPTIONS
HEAD1
HEAD2
HEAD3
HEAD4
MODE
CHANGE
Pitch
-> Normal
NORMAL SAMPLE SELF-TIMING
OPTIONS HEAD1 LASER ON P. 1 PITCH
MASK1:
PITCH No.
NO. OF
PITCHES
MASKING
10
0
MASK2:
PITCH No.
0
MASK3:
PITCH No.
0
AVERAGE 8
DIGIT
SUPPRESS NONE
MEASUR-
ING MODE
NORMAL
SELF-TIMING
INTERVAL (ms) 100
ESC
100 200 500 1000 10 50
OPTIONS HEAD1 LASER ON P. 1 PITCH
MASK1:
PITCH No.
NO. OF
PITCHES
MASKING
10
0
MASK2:
PITCH No.
0
MASK3:
PITCH No.
0
AVERAGE 8
DIGIT
SUPPRESS NONE
MEASUR-
ING MODE
NORMAL
SELF-TIMING
INTERVAL (ms)
100
ESC
■ Setting Procedure
1. Select the OPTIONS screen. Press the [OPTIONS] button.
2. Set the measuring mode.
Press the button corresponding to the head for which the measuring mode is to
be set.
Press this button to select the measuring mode.
Every time you press this button, the display changes in the following order.
[When self-timing mode is selected]
3. Set the self-timing interval.
Every time you press this button, the display changes in the following order.
Note: The self-timing interval can be set only when self-timing mode is selected.
Mode Description
Normal The measured value and differentiation results are displayed/output
at any time.
Sample hold The instantaneous value at a specified time is measured.
Self-timing Automatic measurement without using external synchronous input.
