Chapter 6 Normal Mode
65
6
H H H H H Display Unit
The measured value can be displayed in millimeters or inches.
Note: When the display units setting is changed, the preset values (tolerance
limits, etc.) of the selected program number are reset to the initial settings.
■ Setting Procedure
1. Select the OPTIONS screen.
Press the [OPTIONS] button.
2. Select the UTILITY screen.
Press the [UTILITY] button.
3. Set the display unit.
Press the [DISPLAY UNIT] button to select [mm] or [inch].
Every time you press the button, the display toggles between [mm] and [inch].
OPTIONS UTILITY
LASER ON OPTIONS NOR
MAL P. 1
DISPLAY
DATA
LIMIT
SETUP PROGRAM CALIB OPTIONS
AREA
OUTPUT
INSPECT
UTILITY
Select Option to setup.
MODE
CHANGE
Normal
-> Pitch
LASER ON UTILITY NOR
MAL
P. 1
AREA CHECK
INITIALIZE
ON
PANEL
mm
ONE-SCAN MODE
PROGRAM SELECT
DISPLAY UNIT
ESC
