Chapter 2 Before Using the LS-5000 Series
12
2
2.2 Names and Functions of Indicators and Switches
This section describes the names and functions of the indicators and switches.
■ Names and Functions of Indicators and Switches
Display Name Description
Menu button Used to move to each function’s setup screen.
Setup/Select Used to set values or select settings.
button
Select button Used to select settings or programs.
Screen Select When you press the [Screen Select] button, you
button will move to the screen indicated on the button.
In the example on the left, you will move to the
DISPLAY DATA screen.
Numeric keys Used to set values.
[ENTER] key: Used to accept the setting.
[ESCAPE] key: Used to exit from the numeric keys
screen.
[CANCEL] key: Used to reset the preset value to
zero.
Sign key: Used to change the sign.
[
▲] [ ] keys: Used to move between setting
items.
DISPLAY
DATA
LIMIT
SETUP
7 8 9
4 5 6
1 2 3
0 • – ESCAPE
CANCEL
ENTER
■ Input Procedure Using Numeric Keys
Example: Enter “-5.0000”.
5 • 0 0 0 0 – ESCAPE ENTER
▲
