3 Function Settings
Setting the External Timing Input
The control method for the timing inputs of OUT1 and OUT2 can be set. The following functions
can be specified by the settings.
■
Setting the timing synchronization
1
Hold down the
key, and select "
oPt on
" with the
key.
Set the common settings.
2
Press the
key, and select function
" " with the
key.
Set the synchronization/asynchronization of the external tim-
ing.
3
Press the
key, and select
"
[-1
" with the
key.
"Synchronous" is selected in this example.
4
Press the
key to register the setting. Press the
key to return to the measurement state.
Function No.
Timing
synchronization
Function
[-0
n-Syn[
Asynchronous
Controls OUT1 and OUT2 asynchronously. Assigns
independent input terminals for each of OUT1 and OUT2.
• OUT1: No. 8 of the 12-pin I/O terminal block
• OUT2: No. 6 of the expansion connector
[-1
SYn[
Synchronous
Controls OUT1 and OUT2 synchronously. No. 8 of the 12-
pin I/O terminal triggers OUT1 & OUT2, and
No. 6 of the expansion connector becomes invalid.
Refer to "Chapter 4 Input/Output Terminals" (page 4-1).
OUT1
HI
GO
LO
HI
GO
LO
TIM
OUT2
TIM
OUT1
HI
GO
LO
HI
GO
LO
TIM
OUT2
TIM
OUT1
HI
GO
LO
HI
GO
LO
TIM
OUT2
TIM
Reference
