4-18
4
LK-G-M-NO4-E
4 Input/Output Terminals
Timing details
■ Minimum input time (T1) and input response time (T2)
The sampling rate can be changed according to the setting. Refer to page 3-39.
The measurement response time, measurement average time, RESET time, and refresh rate vary depending
on the sampling rate. Furthermore, when the mutual interference prevention function is turned on, calculate the
value after doubliug the sampling rate (T6 = T6 x 2).
■
Average measurement time, RESET time (T4) and refresh rate (T5)
When the mutual interference prevention function is turned on, calculate the value after doubling the sampling
rate (T6 = T6 x 2).
■ Program No. change time (T7)
When the mutual interference prevention function is turned on, calculate the value after doubling the sampling
rate (T6 = T6 x 2).
Sampling rate (T6) Minimum input time (T1) Input response time (T2)
20 µs 1000 µs 1000 µs + T6 × 2
50 µs
100 µs
200 µs
500 µs
1000 µs 2000 µs 2000 µs + T6 × 2
Filter Average
measurement time
Number of data of
moving average
RESET time (T4) Refresh rate
(T5)
Number of
data to be
averaged
1 T6 × 1 1 T6 × 1 T6 × 1
4 T6 × 4 1 T6 × 4 T6 × 1
16 T6 × 16 1 T6 × 16 T6 × 1
64 T6 × 64 1 T6 × 64 T6 × 1
256 T6 × 256 1 T6 × 256 T6 × 1
1024 T6 × 1024 1 T6 × 1024 T6 × 1
4096 T6 × 4096 1 T6 × 4096 T6 × 1
16384 T6 × 16384 4 T6 × 16384 T6 × 4
65536 T6 × 65536 16 T6 × 65536 T6 × 16
262144 T6 × 262144 64 T6 × 262144 T6 × 64
High-pass filter T6 × 12 T6 × 1
Low-pass filter T6 × 12 T6 × 1
Number of connecting
heads
Sampling rate (T6)
20 µs Other than 20 µs
Single head 60 ms (T6 × 10) + 50 ms
Two heads 50 ms (T6 × 10) + 60 ms
