KEYENCE LK-G Series User Manual
Page 40
1-20
1
LK-G-M-NO1-E
1 Before Use
Combining the separate type controller
1
Install the display panel by aligning it with the two protrusions on the display
panel fixing case.
2
Fix the display panel with the panel attachment ring, and connect the 30-cm display
cable (optional).
3
Align the three claws of the display panel fixing case with the controller.
Display Panel
Two protrusions
Display panel fixing case (optional)
Panel attachment ring
Two claws
Fix the cable by fitting it along the guide.
Display panel fixing case
Controller
Three claws
