KEYENCE LK-G Series - Manual (Page 158)

6-4
6
LK-G-M-NO6-E
6 Specifications of the LK-G Series
Specifications of the Head
■
LK-G15/LK-G10
*1 When the sampling rate is 20 µs, the value becomes +0.37 (FAR side) to –1 mm (NEAR side) at
the time of the diffuse reflection.
*2 The value when measuring the KEYENCE standard target (ceramic) in the standard mode
*3 The value when measuring the KEYENCE standard target (SUS) 4096 times average at the refer-
ence distance.
The value in parenthesis ( ) indicates the typical value when measured with the number of aver-
aging times of 16384.
Model LK-G15/LK-G10
Reference distance 10 mm
Measurement range *1 ±1 mm
Light source Red semiconductor laser
Wavelength 650 nm (visible light) class I (IEC60825-1)
class 2 (CDRH)
Output 0.3 mW max.
Spot diameter (at reference dis-
tance) Approx. 20 x 500 µm (G15)
Approx. ø20 µm (G10)
Linearity *2 ±0.03% of F.S. (F.S. = ±1 mm)
Repeatability *3 0.02 µm (0.01 µm)
Sampling rate 20/50/100/200/500/1000 µs
(Selectable among six steps)
LED indication Near the center of measurement range: Lights in green
Within the measurement range: Lights in orange
Outside the measurement range: Flashes in orange
Temperature characteristics 0.01% of F.S./°C (F.S. = ±1 mm)
Environmental
resistance Enclosure rat-
ing IP67 (IEC60529)
Operating
ambient light Incandescent lamp or fluorescent lamp: 10000 lux max.
Operating
ambient tem-
perature 0 to +50 °C
Operating
ambient
humidity 35 to 85% RH (No condensation)
Vibration resis-
tance 10 to 55 Hz, double amplitude 1.5 mm,
2 hours for each of XYZ axes
Material Aluminum die-cast
Weight (including cable) Approx. 190 g
