ENGINE SYSTEM
2-27 D615-W02 May-2003
d. Cylinder Bore
Cylinder bore inner
diameter 87.000 ~ 87.022 mm
3.4252 ~ 3.4261 in.
83.000 ~ 83.022 mm
3.2677 ~ 3.2690 in.
0.15 mm
0.0059 in.
3A165D
4A200B
e . Valve Spring
41.7 ~ 42.2 mm
1.6417 ~ 1.6614 in.
12.0 kgf / 35.15 mm
26.46 lbs / 1.3839 in.
-
41.2 mm
1.6220 in.
10.2 kgf / 35.15 mm
22.49 lbs / 1.3839 in.
1.0 mm
0.0394 in.
Item Factory Specification Allowable Limit
f. Rocker Arm
18.955 ~ 18.980 mm
0.74600 ~ 0.74724 in.
19.0 ~ 19.035 mm
0.74803 ~ 0.74941 in.
-
-
Item Factory Specification Allowable Limit
Rocker arm shaft O.D
Rocker arm bushing I.D
g. Tappet
0.020 ~ 0.062 mm
0.00079 ~ 0.00244 in.
23.959 ~ 23.980 mm
0.94327 ~ 0.94410 in.
24.000 ~ 24.021 mm
0.94488 ~ 0.94571 in.
0.07 mm
0.0028 in.
-
-
Item Factory Specification Allowable Limit
Clearance between tappet and guide
Tappet O.D
Tappet guide I.D
h. Camshaft
0.01 mm
0.0004 in.
33.59 mm
1.3224 in.
33.69 mm
1.3264 in.
0.050 ~ 0.091 mm
0.00197 ~ 0.00358 in.
39.934 ~ 39.950 mm
1.57221 ~ 1.57284 in.
40.000 ~ 40.025 mm
1.57480 ~ 1.57579 in.
0.05 mm
0.0020 in.
33.54 mm
1.3205 in.
33.64 mm
1.3244 in.
0.15 mm
0.0059 in.
39.88 mm
1.5701 in.
-
Item Factory Specification Allowable Limit
Camshaft alignment
Cam height IN.
EX.
Clearance between camshaft
Camshaft journal O.D
Camshaft counter bore I.D
Free length
Assembling load / assembling length
Squareness
Item Factory Specification Allowable Limit
