CHAPTER 6 8354/8404
6-10 D615-W02 May-2003
615W609A
39.2 ~ 49.0 N·m
4.0 ~ 5.0 kgf·m
28.9 ~ 36.2 lbf·ft
77.5 ~ 90.2 N·m
7.9 ~ 9.2kg f·m
57.1 ~ 66.5 lbf·ft
M12
2
10
2
Left: 1
Right: 1
8
4
Stud.
Stud.
Stud.
Lever shaft
Lever shaft (MID)
Bolt
Bolt
Applicable Model: 8354
Assembly
position (mark)
♣ ♣ ♣ ♣ ♣
Drawing No.
Bolt, Nut Assembly Position and Tightening Torque
Part name Qty. (Bolt) Spec. Tightening torque
01754 - 51235
37150 - 2735-2
01754 - 51285
T2610 - 60561
T2615 - 24432
01173 - 51260
01176 - 51260
39.2 ~ 49.0 N·m
4.0 ~ 5.0 kgf·m
28.9 ~ 36.2 lbf·ft
77.5 ~ 90.2 N·m
7.9 ~ 9.2 kgf·m
57.1 ~ 66.5 lbf·ft
M12
2
12
2
2
Left: 1
Right: 1
6
2
Stud.
Stud.
Stud.
Stud.
Lever shaft
Lever shaft (MID)
Bolt
Bolt
Applicable Model: 8404
Assembly
position (mark)
♣ ♣ ♣ ♣ ♣
Drawing No. Part name Qty. (Bolt) Spec. Tightening torque
01754 - 51235
37150 - 2735-2
01754 - 51285
32435 - 2736-2
T2610 - 60561
T2615 - 24432
01173 - 51260
01176 - 51260
