TRANSMISSION
4-25 D615-W02 May-2003
615W440A
C. Third Stage (Disconnection of Clutch
Housing and Flywheel Housing)
1. Support the lower of clutch housing (1) and engine
with a hydraulic jack.
2. Loosen tightening bolt (3) and nut (4) of clutch hous-
ing and flywheel housing (2).
3. Disconnect the clutch housing and engine.
(When reassembling)
• Apply grease on the spline part.
• Apply a sealing agent on the contacted surface of
clutch housing and flywheel housing.
(1) Clutch Housing (3) Bolt
(2) Flywheel Housing (4) Nut
Sect. Spec. Tightening Torque
Tightening bolt, nut
Stud
M12
M12
77.5 ~ 90.2 N·m
7.9 ~ 9.2 kgf·m
57.2 ~ 66.5 lbf·ft
39.2 ~ 49.0 N·m
4.0 ~ 5.0 kgf·m
28.9 ~ 36.2 lbf·ft
Sealing agent Three bond 1208D or equivalent
