CHAPTER 9 8354/8404
9-24 D615-W02 May-2003
Item
Hydraulic pipe joint bolt
Hydraulic pipe attaching bolt (M10)
Hydraulic block support attaching bolt (M8)
Hydraulic pipe attaching bolt (M8)
Intake pipe 3 attaching bolt (M8)
Filter support attaching bolt (M10)
Hydraulic pump assembly attaching bolt
Rear axle attaching stud
Rear axle attaching bolt, nut
ROPS attaching bolt
M12
M14
M16
M20
Hydraulic cylinder assembly attaching stud (M10)
Hydraulic cylinder attaching bolt, nut (M10)
MLS (Control) valve attaching bolt (M10)
lbf·ft
36.2 ~ 43.4
35.5 ~ 41.2
17.4 ~ 20.2
17.4 ~ 20.2
17.4 ~ 20.2
35.5 ~ 41.2
35.5 ~ 41.2
72.3 ~ 83.1
145 ~ 166
57.1 ~ 66.5
123 ~ 144
192 ~ 224
362 ~ 420
35.5 ~ 41.2
35.5 ~ 41.2
35.5 ~ 41.2
Kgf·m
5.0 ~ 6.0
4.9 ~ 5.7
2.4 ~ 2.8
2.4 ~ 2.8
2.4 ~ 2.8
4.9 ~ 5.7
4.9 ~ 5.7
10.0 ~ 11.5
20 ~ 23
7.9 ~ 9.2
17.0 ~ 20.0
26.6 ~ 31.0
50.0 ~ 58
4.9 ~ 5.7
4.9 ~ 5.7
4.9 ~ 5.7
N·m
49.0 ~ 58.8
48.1 ~ 55.8
23.6 ~ 27.4
23.6 ~ 27.4
23.6 ~ 27.4
48.1 ~ 55.8
48.1 ~ 55.8
98.1 ~ 112.7
197 ~ 226
77.5 ~ 90.2
166.7 ~ 196.1
260.9 ~ 304.0
490 ~ 568
48.1 ~ 55.8
48.1 ~ 55.8
48.1 ~ 55.8
14. TIGHTENING TORQUE
