Cub Cadet 8404 User Manual
Page 110
CHAPTER 4 8354/8404
4-6
D615-W02 May-2003
615W406A
Final Stage
•
When the rotation speed of shift (3) are equal with
that of gear (6), the rotation force of synchronizer
ring (4), will not affect on shift any longer. The Shift
is rotated with the synchronizer ring and gear (6),
engaged for perfect transmission.
(1) Synchro Hub
(4) Synchronizer Spring
(2) Synchronizer Key
(5) Synchronize Ring
(3) Shift
(6) Gear
