Fieldbus Interface PR 5230 Instrument Manual
EN-196 Sartorius
9.4 Fieldbus Register
Register 0: IO Status Bits for Reading
(Dynamic status), only reading is permitted
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 Input 3 Input 2 Input 1
Byte 1 Output 3 Output 2 Output 1
Byte 2 Limit 3 Limit 2 Limit 1
Byte 3
Register 1: Scale Status
(Dynamic status), only reading is permitted
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Byte 0 OUT STND INZSR CZERO BELOW0 OVL >Max ADUERR
Byte 1 E9 E6 E1 E3 E7
Byte 2 PowerFail ActionActive CmdError
Byte 3 TareActive CalActive TestActive
Byte 0 corresponds to byte 7 in the output area; for weight error, see also the table in Chapter 15.1.
ADUERR Error of analog conversion/ load cell circuit (OR function of the E1, E3, E7 bits)
>Max Gross value is higher than Max (FSD); the full scale deflection was exceeded.
OVL Scale overload; Gross >Max + overload, Error 2
BELOW0 Gross weight is negative (<0-¼d)
CZERO Center of zero; weight within 0 ± ¼ d
INZSR The gross weight is within the zero setting range
STND The scale is stable
OUT Below zero or above Max (FSD) (0-¼d >weight value >Max)
E7 The input signal is negative (inverse conversion) , Error 7
E6 No sense voltage, or Sense voltage is low, Error 6
E3 The input signal is >36mV (no end of conversion), Error 3
E1 Arithmetic error (overflow), Error 1
E9 No communication with xBPI scale, Error 9
CmdError Error during execution ( cmdError ); e.g. the 'taring' operation is not handled, because the
scale is not stable. The error is stored in LastError (register 4). The bit is reset with the
ResetError bit (register 121).
ActionActive The operation is handled; handling is busy
PowerFail Power failure; is always set after power on. The PowerFail bit is reset with the ResetPWF
bit (register 85) 'Reset power failure'.
TestActiv The analog test is busy
CalActive The instrument is/was configured. When this bit is 1, the scale parameters
(Expo/Unit/Step) must be read again. Set after power On and reset after reading the
max. capacity.
TareActiv The instrument was tared.
