Commissioning PR 5230 Instrument Manual
EN-138 Sartorius
5.5.10 xBPI Calibration with Built-in Weight
Prerequisites:
-
The xBPI protocol has been selected (see Chapter 5.5.1).
- The weighing point ‚xBPI-scale’ has been selected (see Chapter 5.5.4).
- The platform configuration has been executed (see Chapter 5.5.3).
- The setting in the following menu has been done: [Weighingpoint A-xBPI-Scale]-[Setup]:
[Configuration]-[Confirming adjust.]: [manual] (see Chapter 5.5.5).
- The communication between instrument and platform is active.
Weighingpoint/ xBPI-Scale Setup
Calibration Open with
.
Configuration
Select group of specification
Show device info
Weighingpoint/ xBPI-Scale Setup
Adjust with default weight
Adjust with intern weight
Select with and enter with .
Linearity
Default
User
The procedure is shown e.g. with the following message:
Weighingpoint/ xBPI-Scale Setup
Calibration status Motor in motion The calibration progress is displayed.
Accept ResError Abort
Weighingpoint/ xBPI-Scale Setup
Calibration status Difference display
Cal-Delta 0.0 g
-- 1212.73 g
Select [Accept]. Accept ResError Abort
The data are saved and the instrument generates a corresponding message:
Weighingpoint/ xBPI-Scale Setup
Calibration status complete
Net=Grs -0.0 g
-- -0.06 g
Leave with . Accept ResError Abort
