PR 5230 Instrument Manual
Transmitter in Field Housing
Sartorius
EN-15
2.3.1.1
Status Indication
For status indication, max. 5 lines can be configured by selecting from a menu (see Chapter 5.6.7).
Selection
Width
Height
Example
Description
Empty
½ Display
1 Line
Empty line
Gross/Net/Tare
½ Display
1 Line
B
+123.45kg
Gross/Net/Tare
B
E:Sense
Error, see Chapter 15.1
Gross
½ Display
1 Line
B
+123.45kg
Gross
Net
½ Display
1 Line
NET
+123.45kg
Net
Tare
½ Display
1 Line
T
+123.45kg
Tare
Bargraph
1 Display
1 Line
Shows the weight in
proportion to nominal
capacity.
Fieldbus LEDs
½ Display
1 Line
––– red ––– grn
See Chapter 4.4.
Fieldbus Inputs
1 Display
1 Line
FB-Inp: 01.23.45.67.89.AB.CD.EF Fieldbus Inputs
Fieldbus Outputs
1 Display
1 Line
FB-Out: 01.23.45.67.89.AB.CD.EF Fieldbus Outputs
Digital inputs
½ Display
1 Line
Inputs:
Digital inputs: 1, 2, 3
Digital outputs
½ Display
1 Line
Outputs:
Digital outputs: 1, 2, 3
Digital I/O
½ Display
1 Line
I: O:
Digital in-/outputs: 1, 2, 3
Analog output
½ Display
1 Line
Ana:
12.345mA
Analog output
Limits
½ Display
1 Line
Limits:
Limits: 1, 2, 3
Date
½ Display
1 Line
2009-12-31
Date
Time
½ Display
1 Line
10:37:34
Time
Hostname
½ Display
1 Line
HOPPER1
Device name in the network
Hostname (long)
1 Display
1 Line
Small Material Hopper Device name (long)
IP-Address
½ Display
1 Line
192.168.1.1
Network address
---.---.---.---
No network
??.??.??.??
Search DHCP server
IP-Address (long)
1 Display
1 Line
172.200.280.255
Network address (long)
Gross (2 lines high)
1 Display
2 Lines
B
+123.45 kg
Gross (2 lines high)
Net (2 lines high)
1 Display
2 Lines
NET
+123.45 kg
Net (2 lines high)
Tare (2 lines high)
1 Display
2 Lines
T
+123.45 kg
Tare (2 lines high)
