Commissioning PR 5230 Instrument Manual
EN-146 Sartorius
[-none-]
Nothing is printed. The function can be used for printing less than 6 data items.
[Displayed weight], [Grossweight], [Net weight], [Tare weight]
The displayed gross, net or tare weight is printed. If [OIML], [NTEP] or [NSC] has been selected, printing is done
only, if the stability criteria is fulfilled, the weight is shown in '< >'. For [NTEP] or [NSC] the gross weight is
indicated with G (else B).
[Date & Time]
The date and time are printed as DD.MM.YYYY HH:MM:SS
Example for printing
PrintlayoutItem1 Date & Time
PrintlayoutItem2 Sequencenumber
PrintlayoutItem3 Grossweight
PrintlayoutItem4 Net weight
PrintlayoutItem5 CR/LF
PrintlayoutItem6 -none-
5.6.5 Fieldbus parameter
This menu item can only be selected if a fieldbus card is installed in slot 2.
Which protocol is displayed automatically depends on the Fieldbus card installed:
[ProfiBus-DP] for PR 1721/41, [InterBus-S] for PR 1721/42, [DeviceNet] for PR 1721/44, [ProfiNet I/O] for PR
1721/46 and [EtherNet-IP] for PR 1721/47.
Define the fieldbus parameters under -[ Fieldbus parameter ].
Which additional parameters are required, depends on the interface type.
Press
to select the specific parameter.
Press to select the respective values.
[ProfiBus-DP]
Setup/ Fieldbus parameter
fieldbus protocol ProfiBus-DP
ProfiBus-DP address 1 Enter address
[InterBus-S]
Setup/ Fieldbus parameter
Fieldbus protocol InterBus-S
[DeviceNet]
Setup/ Fieldbus parameter
Fieldbus protocol DeviceNet
DeviceNet baudrate 500k Select 500, 250 or 125 k
DeviceNet MAC-ID 1 Enter address 1 ... 62
