PR 5230 Instrument Manual Commissioning
Sartorius EN-119
5.4.8 Calibration with Load Cell Data (smart calibration)
If the scale is not ‘legal for trade’, calibration without weights can be performed. The easiest method is the one
using load cell data without calculation [by data].
Weighingpoint/WP A/ Calibration
Max 3000 d 3000 kg
Scale interval 3000 d 1 kg
Deadload at 3.00 kg 0.001000
Max at 3000.00 kg 0.000000
Not calibrated
Sensitivity 833.33 4.000000
by load by mV/V by data Linear. CalcTest
Start by pressing [by data].
Weighingpoint/WP A/Calibration/ Load cell configuration
Number of load cells 4
Nominal load 3000 kg
Gravity 9.81379 m/s²
Hysteresis error not specified
Certified data all LC same
LC sensitivity 1.000000
Enter Calc
Weighingpoint/WP A/Calibration/ Load cell configuration
LC resistance 600.000 ¥
Enter Calc
[Number of load cells]
Number of load cells connected in parallel (1, 2...<4>...9, 10)
[Nominal load]
Max. capacity E
max
of a load cell (not the overall nominal weight of the scale!)
[Gravity]
Acceleration of gravity at the place of installation; default is the value for Hamburg, Germany 9.81379 m/s².
[Hysteresis error]
When switching from [Not specified] to [Specified], values for [Correction A/B] must be filled in. The data is
given on the load cell certificate.
[Certified data], [LC sensitivity], [LC resistance]
With [all LC same] only 1 value for the sensitivity [LC sensitivity] and the output resistance [LC resistance] must
be filled in. With [each LC specific] individual values for each load cell are requested.
[Calc]
The mV/V value is calculated and after confirmation with [OK], the calculated mV/V value is stored in the
calibration data.
