5.5.7 xBPI Calibration with the User Weight
Prerequisites:
-
The xBPI protocol has been selected (see Chapter 5.5.1).
- The weighing point ‚xBPI-scale’ has been selected (see Chapter 5.5.4).
- The platform configuration has been executed (see Chapter 5.5.3).
- The setting in the following menu has been done: [Weighingpoint A-xBPI-Scale]-[Setup]:
[Configuration]-[Confirming adjust.]: [manual] (see Chapter 5.5.5).
- The communication between instrument and platform is active.
Weighingpoint/ xBPI-Scale Setup
Calibration Open with
.
Configuration
Select group of specification
Show device info
Weighingpoint/ xBPI-Scale Setup
Dead load
Set
Delete
Span
Adjust with user weight
Select with and enter with .
Adjust with auto weight
Enter user weight The previously stored user weight is displayed.
2000 g The weight can be changed.
Following window appears:
Weighingpoint/ xBPI-Scale Setup
Calibration status Load to small Calibration progress without weight.
Cal-Target -2000 g
-- 0.01 g
The following window is displayed after applying the weight:
Weighingpoint/ xBPI-Scale Setup
Calibration status Difference display
Cal-Delta -0.3 g
-- 1999.75 g The weight is displayed in high-resolution (10x).
Select [Accept].
Accept ResError Abort
