5.4.4 Determining the Scale Interval
The scale interval (d) is the difference between two successive display values.
With a legal-for-trade weigher, this value is called “verification scale interval“, which corresponds to the scale
interval:
d = e.
Example
Max = 3000 kg
Scale division = 1
Calculation (automatic):
d = Max / scale division
d = 3000 kg / 1 kg
d = 3000
Weighingpoint/WP A/ Calibration
Max 3000 d 3000 kg
Scale interval 3000 d 1 kg The scale division 1, 2, 5 10, 20 or 50
can be set by pressing .
The scale interval [d] is calculated from the scale division and the Max weight value.
The weight unit is taken from [Max] and cannot be changed here.
The number of digits behind the decimal point has been determined already when entering [Max] as well.
After
or confirmation of the change is displayed with:
Set Scale interval
This message displays, if the maximum capacity [Max] of the scale range
(weighing range) is not an integer multiple of the scale interval.
