PR 5230 Instrument Manual Asycom Protocol
Sartorius EN-187
8.2 Other Commands
Command Reply Description
ZSDTTMMJJJJssmm QZSD Set date and time
Possible error messages:
E20000 telegram too long
E60000 telegram too short
ZSC QZSC Reset communication
V QV5230-1.00 Version request
LV QLVxxxx/xx-
x.xxaaaaaa
dssnnnnnttttt xxxx/xx-x.xx = instrument version
aaaaaa = Max in 5 digits with dec. point
d = Unit, variable (mg, g, kg, t, lb, oz)
ss = Scale interval (01, 02, 05, 10, 20, 50)
nnnnn = Span in mV/V (e.g. 01234 acc. to 0.1234 mV/V)
ttttt = deadload in mV/V
(e.g. 00234 acc. to 0.0234 mV/V)
8.3 SPM Commands
Command Reply Description
mrx qmrx<0q>
Read SPM bit
mrb qmrb
Read SPM byte
mrw qmrw
Read SPM word
mrd qmrd
mrb qmrb
Read SPM bytes
mrw qmrw
Read SPM words
mrd qmrd
Read SPM double words
Length 1 can be omitted.
msx q
Set bit
mcx q
Clear bit
msb q
Set byte
mcb q
Clear byte
msw q
Set word
mcw q
Clear word
msd q
Set double word
mcd q
Clear double word
mwx<0q> q
Write SPM bit
mwb q
Write SPM byte
mww q
Write SPM word
mwd q
Write SPM D word
mwb q
Write nn SPM bytes
mww q
Write nn SPM words
mwd
Write nn SPM D words
Length 1 can be omitted. An AND/OR function is also possible.
