PR 5230 Instrument Manual Commissioning
Sartorius EN-103
5.3.6 Function INFO
When you press the program releases and status messages are displayed. The key also has other
functions; see Chapters 5.4.1.1 and 5.4.9.
Info
Show version
Show status
Show HW-slots
When you select [Show version], the installed program releases and the board number are displayed:
Info/ Version
Firmware Rel. 03.00.00.00000 Firmware release and creation date
2011-10-10 11:11
Application Rel. 01.20.05 Application release and creation date
2010-11-11 11:11
Bios Rel 02.00.00.00000 BIOS release and creation date
2010-11-11 11:11
Boardnumber 327923612 Main board identification number
(different from the device serial number)
When you select [Show status], instrument status information is displayed:
Info/ Status
Free system RAM 5328 of 15204 kb
CAL-Switch opened opened = CAL switch is open,
closed = CAL switch is closed.
Builtin RS232 no signal
When you select [Show HW-slots], the installed plug-in cards are displayed:
Info/ HW-Slots
Builtin RS485 Firmly installed serial interface
Builtin RS232 Firmly installed serial interface
Builtin analog out Optional interface (Slot 1, B1*)
Builtin digital i/o Firmly installed digital interface
PR1721/41 ProfiBus-DP Only field bus cards (Slot 2, B2*)
PR5230/xx ADC For weighing electronics board (W1 or WE1)
When selecting ‚PR5230/xx’, factory serial number and production date are displayed:
Serial No 30252 00055
Prod.date: 2010-04-26 13:48:30
5.3.7 Setup Function (VNC)
Press to configure the main operating parameters. The configuration depends on the application licenses
registered and the plug-in cards installed.
Calibration is in a simple dialogue. Compliance with the relevant (verification) standards must be checked by
the person commissioning the instrument or the verification officer. To protect the calibration data from
overwriting, close the corresponding CAL switch on the weighing electronics board. On legal-for trade
instruments, the CAL switch must be sealed in the closed (write-protected) position; see Chapter 5.1.1.
