Publication 1757-UM006A-EN-P May 2002
Appendix
F
1788-CN2FF Installation Example
Overview This installation example provides a step by step approach to the installation
of the 1788-CN2FF. For more information on the operation the 1788-CN2FF,
and its companion software, the 1788-FFCT, Foundation Fieldbus
Configuration Tool refer to Chapter 7, Using the 1788-CN2FF,
ControlNet-to-FOUNDATION Fieldbus H1 Linking Device.
For more information on Foundation Fieldbus visit www.Fieldbus.org .
Table F.1 Topics Covered in the Installation Example
Topics: Page:
Required Hardware for Installation Example F-2
Required Software F-3
Example Description F-3
Connecting the Hardware F-5
Install the 1788-FFCT Software F-6
Assigning a Path to the 1788-CN2FF F-10
Installing Device Descriptions (DDs) F-14
Starting NIFB F-17
Troubleshooting the Port Configuration F-18
Modifying Device and Function Block Names F-24
Configuring the Fieldbus Device F-29
Sending Data To the PLC-5, CLX, PLX or SLC F-36
PLC-5 and ControlLogix Applications F-40
ControlLogix Application F-41
Testing the Installation Example F-46
Remote Configuration of a Fieldbus Network via the 1788-CN2FF F-49
Troubleshooting an Application F-51
