D-4 Fieldbus Wiring Considerations
The following table lists limits for some possible fieldbus cable types
listed in the order of usage preference with 1 being preferred.
Another rule of thumb based on Fieldbus Foundation published
guidelines is for the length of spurs and how many devices can be on
various lengths of cable as listed in the following table.
Table D.2 Fieldbus Cable Limits
Preference
Type
Description
Distance
(Meters/Feet)
Resistance
(Ohms per km)
Attenuation
(dB per km)
1
#18 AWG, shielded,
twisted pair
1900/6233
22
3
2
#22 AWG,
multiple-twisted,
pairs with overall
shield
1200/3937
56
5
3
#26 AWG,
multiple-twisted,
pairs without shield
400/1312
132
8
4
#16 AWG, multiple
conductor, no
twisted pairs with
overall shield
200/656
20
8
Table D.3 Number of devices on the fieldbus and maximum spur length
Number of Devices
Maximum Spur Length (Meter/Feet)
1 to 12
120/394 (one device per Spur)
13 to 14
90/295 (one device per Spur)
15 to 18
60/197 (one device per Spur)
19 to 24
30/98 (one device per Spur)
25 to 32
No spurs allowed
ATTENTION
!
The spur length limitations are for spurs with one
device each. Please refer to the Fieldbus Foundation
AG-140 Wiring and Installation Guide for rules on
multiple devices per spur.
