A-4 Standard Function Block Parameters
Table A.9 BKCAL_OUT
Table A.10 BKCAL_OUT_D
Valid Views
VIEW_3
Storage
Non-Volatile
Remarks
The data type consists of the value and status of floating point parameters
that are Inputs or Outputs. It uses the following two elements.
• Status
• Value
Classification
Record
Description
The value and status required by an upper block's BKCAL_IN so the upper
block may prevent reset windup and provide bumpless transfer to closed loop
control.
FF Data Type
DS-65
Usage
O/Back Calculation Output
Length
5
Valid Views
VIEW_3
Storage
Dynamic
Remarks
The data type consists of the value and status of floating point parameters
that are Inputs or Outputs. It uses the following two elements.
• Status
• Value
Classification
Record
Description
The output value and status provided to an upstream discrete block that is
used to provide bumpless transfer for closed loop control.
FF Data Type
DS-66
Usage
O/Back Calculation Output
Length
2
Valid Views
VIEW_3
Storage
Dynamic
Remarks
The data type consists of the value and status of discrete value parameters. It
uses the following two elements.
• Status
• Value
