Rockwell Automation PLC-5 Fieldbus Solutions for Integrated Architecture User Manual User Manual
Page 236

Publication 1757-UM006A-EN-P - May 2002
C-2 Mode Change Conditions
Target mode is CAS and
cascade input status is not
Good - Initialization
Acknowledge and actual mode
attribute last execution was not
CAS
N/A
N/A
N/A
Actual mode
from last
execution or
AUTO
N/A
N/A
Status attribute of primary input
parameter is BAD or Uncertain
with option to treat Uncertain
as BAD and bypass not set
OOS
MAN
MAN
MAN
MAN
ROUT
Status attribute of back
calculation input parameter is
BAD
OOS
IMAN
IMAN
IMAN
IMAN
IMAN
Status attribute of back
calculation input parameter
Good - failsafe active, local
override, not invited, or
initialization request
OOS
IMAN
IMAN
IMAN
IMAN
IMAN
Tracking is enabled, track input
active and track override
manual is Enabled.
OOS
LO
LO
LO
LO
LO
Tracking is enabled, initiated
and track override manual is
Disabled.
OOS
MAN
LO
LO
LO
LO
Failsafe is active in an output
function block
OOS
LO
LO
LO
LO
LO
If target mode has changed
from OOS to another mode
since the block was last
executed.
-
MAN
MAN
MAN
MAN
MAN
Resource state as reflected in
the resource block parameter
resource state is Standby.
OOS
OOS
OOS
OOS
OOS
OOS
(1)
Shed to the next lowest priority, non-remote mode which is permitted or, optionally, which is retained by the target mode
attribute and for which the required inputs are available.
Input Parameters Status
Attributes, Inputs Values and
Resource States
Mode Parameter - Target Attribute Value
Out of Service
(OOS)
Manual
(MAN)
Automatic
(Auto)
Cascade
(CAS)
Remote
Cascade
(RCAS)
Remote
Output
(ROUT)
