Page 199

Publication 1757-UM006A-EN-P - May 2002
Standard Function Block Parameters A-19
Table A.51 FSAFE_VAL_D
Gxxx Blocks
Table A.52 GAIN
Table A.53 GRANT_DENY
Classification
Simple Variable
Description
Defines the preset discrete setpoint to use when a failure occurs. Value is
ignored, if the IO_OPTS Failsafe to value option is false.
FF Data Type
Unsigned 8
Usage
C/Contained
Length
1
Valid Views
VIEW_4
Storage
Static
Classification
Simple Variable
Description
Represents dimensonless gain used by several different algorithms.
FF Data Type
Float
Usage
C/Contained
Length
4
Valid Views
VIEW_4
Storage
Static
Classification
Record
Description
Defines options for controlling access of host computer or local control panels
to the block's operating, tuning, and alarm parameters.
FF Data Type
DS-70
Usage
C/Access Permission
Length
2
Valid Views
VIEW_2
Storage
Non-Volatile
Remarks
The data type consists of access control flags for access to block parameters.
It uses the following two elements.
• Grant
• Deny
