Publication 1757-UM006A-EN-P - May 2002
Configurating the 1757-FIM 4-27
Assigning a Device to a Link in Project
Use the following procedure to assign a device to a Link associated
with the applicable FIM in the Project tab.
1. Click Tools
⇒
Assign. Or, click the assign button
in the
toolbar.
The Controller Assignments window opens.
2. Click the Devices tab.
3. Click the device you want to assign to a Link to highlight it.
4. Confirm that the desired Link is selected in the Select Link list
box.
5. Click Assign to assign the selected device to the selected Link.
The device is added to the Assigned Devices box with the assign
state icon.
6. Click Close.
