Publication 1757-UM006A-EN-P - May 2002
A-42 Standard Function Block Parameters
Table A.112 SIMULATE
Table A.113 SIMULATE_D
Table A.114 SP
Classification
Record
Description
Allows the transducer analog input or output to the block to be manually sup-
plied, when SIMULATE is enabled. When SIMULATE is disabled, the simulate
value and status track the actual value and status.
FF Data Type
DS-82
Usage
C/Simulate
Length
11
Storage
Dynamic
Remarks
The data type consists of simulate and transducer floating point value and sta-
tus and a simulate enable/disable discrete. It uses the following five ele-
ments.
1: Simulate Status
2:Simulate Value
3: Transducer Status
4: Transducer Value
5: Simulate Enable/Disable
Classification
Record
Description
Allows the transducer discrete input or output to the block to be manually sup-
plied, when SIMULATE is enabled. When SIMULATE is disabled, the simulate
value and status track the actual value and status.
FF Data Type
DS-83
Usage
C/Simulate
Length
5
Storage
Dynamic
Remarks
The data type consists of a simulate and transducer discrete value and status
and a simulate enable/disable discrete. It uses the following five elements.
1: Simulate Status
2:Simulate Value
3: Transducer Status
4: Transducer Value
5: Simulate Enable/Disable
Classification
Record
Description
Defines the setpoint of any analog block.
FF Data Type
DS-65
Range
PV_SCALE +/- 10 percent
Usage
C/Setpoint
Length
5
