Rockwell Automation 23P PowerFlex Digital DC Drive User Manual
Page 248

248
Rockwell Automation Publication 20P-UM001K-EN-P - July 2014
Appendix A
Supplemental Drive Information
Table 71 - Leg Fuses - 460V AC Input Frame D Drives
Table 72 - AC Input Line Fuses - 575V AC Input Frame C Drives
Table 73 - Leg Fuses - 575V AC Input Frame D Drives
Table 74 - AC Input Line Fuses - 690V AC Input Frame C Drives
Table 75 - Leg Fuses - 690V AC Input Frame D Drives
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC Line
Amps
Qty
Bussmann
Mersen
SIBA
Square Body - DIN 43653 Stud-Mount
D
830
830
678.1
6
170M6262 + switch 170H0069
X300262 + switch MS 3V 1-5 UR
20 635 32.800 + switch 28 001 04
996
996
813.7
6
170M6264 + switch 170H0069
Z300264 + switch MS 3V 1-5 UR
20 635 32.1000 + switch 28 001 04
1K1
1162
949.4
6
170M6265 + switch 170H0069
A300262 + switch MS 3V 1-5 UR
20 635 32.1100 + switch 28 001 04
1K3
1328
1085.0
6
170M6266 + switch 170H0069
B300266 + switch MS 3V 1-5 UR
20 635 32.1250 + switch 28 001 04
1K4
1494
1220.6
6
170M6267 + switch 170H0069
C300267 + switch MS 3V 1-5 UR
20 635 32.1400 + switch 28 001 04
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Qty Bussmann
Mersen
SIBA
Square Body - Flush End Contact
C 540
540
441
3
170M5466 + switch 170H0069
6,9 URD 32 TTF 1000 + switch MS 3V 1-5 BS
20 671 32.1000 + switch 28 001 04
675
675
551
3
170M5466 + switch 170H0069
6,9 URD 32 TTF 1000 + switch MS 3V 1-5 BS
20 671 32.1000 + switch 28 001 04
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC Line
Amps
Qty
Bussmann
Mersen
SIBA
Square Body - DIN 43653 Stud-Mount
D
810
810
661
6
170M6262 + switch 170H0069
X300262 + switch MS 3V 1-5 UR
20 635 32.800 + switch 28 001 04
1K0
1080
881
6
170M6264 + switch 170H0069
Z300264 + switch MS 3V 1-5 UR
20 635 32.1000 + switch 28 001 04
1K2
1215
991
6
170M6265 + switch 170H0069
A300262 + switch MS 3V 1-5 UR
20 635 32.1100 + switch 28 001 04
1K3
1350
1102
6
170M6266 + switch 170H0069
B300266 + switch MS 3V 1-5 UR
20 635 32.1250 + switch 28 001 04
1K6
1688
1377
12
170M6262 + switch 170H0069
X300262 + switch MS 3V 1-5 UR
20 635 32.800 + switch 28 001 04
Fr
am
e
Drive
Current
Rating
Code
DC
Amps
AC
Line
Amps
Qty Bussmann
Mersen
SIBA
Square Body - Flush End Contact
C 452
452
369
6
170M5463 + switch 170H0069
6,9 URD 32 TTF 0700 + switch MS 3V 1-5 BS
20 671 32.700 + switch 28 001 04
565
565
461
6
170M5465 + switch 170H0069
6,9 URD 32 TTF 0900 + switch MS 3V 1-5 BS
20 671 32.900 + switch 28 001 04
Fram
e
Drive
Current
Rating
Code
DC
Amps
AC Line
Amps
Qty
Bussmann
Mersen
SIBA
Square Body - DIN 43653 Stud-Mount
D
678
678
553
6
170M6260 + switch 170H0069
V300260 + switch MS 3V 1-5 UR
20 635 32.630 + switch 28 001 04
791
791
645
6
170M6262 + switch 170H0069
X300262 + switch MS 3V 1-5 UR
20 635 32.800 + switch 28 001 04
904
904
738
6
170M6263 + switch 170H0069
Y300263 + switch MS 3V 1-5 UR
20 635 32.900 + switch 28 001 04
1K0
1017
830
6
170M6264 + switch 170H0069
Z300264 + switch MS 3V 1-5 UR
20 635 32.1000 + switch 28 001 04
1K1
1130
922
6
170M6265 + switch 170H0069
A300262 + switch MS 3V 1-5 UR
20 635 32.1100 + switch 28 001 04
1K2
1243
1014
6
170M6266 + switch 170H0069
B300266 + switch MS 3V 1-5 UR
20 635 32.1250 + switch 28 001 04
1K4
1413
1153
6
170M6267 + switch 170H0069
C300267 + switch MS 3V 1-5 UR
20 635 32.1400 + switch 28 001 04
1K5
1582
1291
12
170M6262 + switch 170H0069
X300262 + switch MS 3V 1-5 UR
20 635 32.800 + switch 28 001 04
