Rockwell Automation Publication 20P-UM001K-EN-P - July 2014 223
Troubleshooting Chapter 4
Table 41 - Fault Cross Reference by Number
No. (1)
(1) Fault numbers not listed are reserved for future use.
Fault No. (1) Fault
2 Auxiliary Input 81…85 Port 1 DPI Loss
3 Power Failure Port 2 DPI Loss
4 AC Undervoltage Port 3 DPI Loss
5 Arm Overvoltage Port 4 DPI Loss
6 Fld Current Loss Port 5 DPI Loss
7 Motor Overload 89 Shorted SCR
8 Heatsink OvrTemp 90 Open SCR
10 Main Contactor 91 Speed Fdbk Loss
13 Overcurrent 92 Encoder Error
16 Motor Over Temp 93 Resolver Error
25 Overspeed 94 TorqPrv Spd Band
37 Inverting Fault 95 Fwd End Limit
48 Params Defaulted 96 Rev End Limit
56 STune Overspeed 97 Fwd Over Travel
57 STune Stalled 98 Rev Over Travel
58 STune LoadHi 99 Travel Lim Cflct
59 STune CurLimit 100 EEPROM Error
60 STune FrictionLo 130 Hardware Fault
61 STune Timeout 131 Interrupt Error
62 STune Aborted 132 Dsp Error
64 Drive Overload
70 Sustained Curr
71…75 Port 1 Adaptor
Port 2 Adaptor
Port 3 Adaptor
Port 4 Adaptor
Port 5 Adaptor
