Rockwell Automation 23P PowerFlex Digital DC Drive User Manual
Page 144
144
Rockwell Automation Publication 20P-UM001K-EN-P - July 2014
Chapter 3
Programming and Parameters
MO
TO
R C
O
NT
ROL
Te
st
G
ene
rator
214
[SCR Diag Status]
Bits 0…11 indicate which SCR or SCR pair is in error. The type of error is indicated in bits 13…15. Only one type of error is shown at a time. The
precedence of errors is “Shorted SCR,” “OpenSCR Trip,” and “OpenSCR Warn.” Note that “OpenSCR Warn” is independent from a SCR trip configured as an
alarm. This parameter is only active when bit 0 “OpenSCR Tst” or bit 1 “ShortSCR Tst” of Par 213 is set to 1 “Enabled.” The SCR numbering shown is
SCR1…SCR6 for the forward power bridge and SCR11…SCR16 for the reverse bridge (regenerative drives only). In the standard drive, SCRx corresponds
to the SCR package labelled KGx and SCR1x to the package labelled KG0x. See the appropriate PowerFlex DC Drive Hardware Service Manual for your drive
frame size for instructions on replacing SCR modules. For frame A drives, see
. For frame B drives
For frame C drives, see
or frame D drives
.
Note: This parameter was added for firmware version 6.001.
213,
215,
216,
217,
218
215
[OpenSCR WarnLvl]
Sets the open SCR warning level. This value determines when Par 214 [SCR
Diag Status], bit 13 “OpenSCR Warn” is set. This parameter is only active
when Par 213 [SCR Diag Test En], bit 0 “OpenSCR Tst” is enabled.
Note: This parameter was added for firmware version 6.001.
Default:
Min/Max:
1024
0 / 4096
16-bit
Int
213
216
[OpenSCR Flt Cfg]
Configures the open SCR error condition. This parameter is only active when
Par 213 [SCR Diag Test En], bit 0 “OpenSCR Tst” is enabled.
Note: This parameter was added for firmware version 6.001.
Default:
Options:
0 =
0 =
1 =
2 =
“Ignore”
“Ignore”
“Alarm”
“Fault”
16-bit
Int
213
217
[OpenSCR Threshld]
Sets the open SCR error level and when exceeded begins to accumulate. This
parameter is only active when Par 213 [SCR Diag Test En], bit 0 “OpenSCR Tst”
is enabled.
Note: This parameter was added for firmware version 6.001.
Default:
Min/Max:
Units:
50
0 / 100
%
16-bit
Int
213
218
[OpenSCR Trip Lvl]
Sets the open SCR trip level. The action taken by the drive when as open SCR
trip occurs is determined by Par 216 [OpenSCR Flt Cfg]. This parameter is only
active when Par 213 [SCR Diag Test En], bit 0 “OpenSCR Tst” is enabled.
Note: This parameter was added for firmware version 6.001.
Default:
Min/Max:
1024
0 / 4096
16-bit
Int
213,
216
Fil
e
Gr
oup
No
.
Parameter Name & Description
See
page 114
for symbol descriptions
Values
Da
ta
T
yp
e
Rela
ted
A
Options
Shor
te
d SCR
Op
en
SC
R T
rip
Op
en
SC
R W
ar
n
Re
se
rv
ed
SCR
16
SCR
15
SCR
14
SCR
13
SCR
12
SCR
11
SCR
6
SCR
5
SCR
4
SCR
3
SCR
2
SCR
1
Default
0
0
0
x
0
0
0
0
0
0
0
0
0
0
0
0
Bit
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
A
A
A
A
