Rockwell Automation Publication 20P-UM001K-EN-P - July 2014 207
Programming and Parameters Chapter 3
Spd Reg Kp Base 93 Autotune 140
Spd Reg Kp Outpt 99 Speed Regulator 146
Spd Reg Neg Lim 96 Speed Regulator 146
Spd Reg Out Pct 236 Speed Regulator 124
Spd Reg Pos Lim 95 Speed Regulator 146
Spd Select 0 400 Diagnostics 177
Spd Select 1 401 Diagnostics 177
Spd Select 2 402 Diagnostics 177
Spd Trq Mode Sel 241 Control Config 149
Spd Tune Inertia 1030 Autotune 141
Spd Up Gain Pct 445 Speed Regulator 150
Spd Zero I En 123 Speed Regulator 148
Spd Zero P En 125 Speed Regulator 148
SpdFuncSelect 1016 Speed Regulator 150
SpdReg AntiBckup 643 Speed Regulator 150
SpdReg BW Bypass 448 Speed Regulator 150
SpdOut FiltBW 239 Speed Regulator 149
SpdOut FiltGain 238 Speed Regulator 149
SpdReg FB Bypass 458 Speed Feedback 139
SpdReg Ki Bypass 460 Speed Regulator 150
SpdReg Ki Pct 1035 Autotune 141
SpdReg Kp Bypass 459 Speed Regulator 150
SpdReg Kp Pct 1034 Autotune 141
SpdReg NegLmOut 90 Current Meters 125
SpdReg PosLmOut 89 Current Meters 125
SpdTune Friction 1031 Autotune 141
Speed Demand En 1215 Winder
Functions
167
Speed Dev Band 1105 Torque Prove 170
Speed Draw Out 1018 Speed Meters 125
Speed Match 1195 Winder
Functions
166
Speed Ramp En 245 Ramp Rates 152
Speed Ratio 1017 Speed
References
146
Speed Ref A 44 Speed Meters 123
Speed Ref A Pct 47 Speed Meters 123
Speed Ref B 48 Speed Meters 123
Speed Ref B Pct 49 Speed Meters 123
Speed Ref Out 385 Speed Meters 124
Speed Ref Source 1329 Diagnostics 178
Speed Reg En 242 Speed Regulator 149
Speed Reg In 118 Speed Meters 124
Speed Reg In Pct 117 Speed Meters 123
Speed Thresh Neg 102 Speed Regulator 147
Speed Thresh Pos 101 Speed Regulator 147
Speed Threshold 393 Diagnostics 176
Speed Tune Dir 1029 Autotune 141
Speed Tune Ki 1033 Autotune 141
Speed Tune Kp 1032 Autotune 141
Speed Up Base 446 Speed Regulator 150
Name No. Group Page
Speed Up Filter 447 Speed Regulator 150
Speed Zero Delay 108 Speed Regulator 148
Speed Zero Level 107 Speed Regulator 148
Spd Zero P Gain 126 Speed Regulator 149
Start At Powerup 1344 Restart Modes 155
Start Inhibits 1403 Diagnostics 180
Start Mask 592 Masks & Owners 187
Start Owner 601 Masks & Owners 188
Static F Zero 1287 Winder
Functions
168
Static Friction 1174 Winder
Functions
164
Status1 at Fault 1349 Faults 180
Status2 at Fault 1350 Faults 180
Stop Owner 600 Masks & Owners 188
Tachometer Speed 1408 Speed Meters 125
Taper Enable 1176 Winder
Functions
165
TaskLoad 1 ms 1384 Diagnostics 179
TaskLoad 2 ms 1385 Diagnostics 179
TaskLoad 8 ms 1386 Diagnostics 179
TB Manual Ref 267 Discrete Speeds 146
Tension Reduct 1179 Winder
Functions
165
Tension Ref 1180 Winder
Functions
165
Tension Scale 1181 Winder
Functions
165
TestPoint Data 1382 Diagnostics 179
TestPoint Sel 1381 Diagnostics 179
Threshold Delay 103 Speed Regulator 147
Time AccDec Min 1182 Winder
Functions
165
Torq Cur Filter 926 Torq Attributes 134
Torq Current Pct 1193 Winder
Functions
166
Torq Limit Slew 1104 Torque Prove 170
Torq Limit Type 715 Load Limits 154
Torq Prove Cfg 1100 Torque Prove 169
Torq Prove Setup 1101 Torque Prove 169
Torq Prove Sts 1103 Torque Prove 170
Torq Red CurLim 13 Load Limits 153
Torque Const 1013 Autotune 141
Torque Negative 347 Diagnostics 174
Torque Positive 346 Diagnostics 174
Torque Reduction 342 Torq Attributes 134
Torque Ref 39 Torq Attributes 133
Torque Winder En 1209 Winder
Functions
166
Total Inertia 433 Speed Regulator 149
Trim Ramp 42 Speed Reference 146
Trim Ramp Pct 378 Speed Reference 146
Name No. Group Page
Trim Speed 43 Speed Reference 146
Trim Speed Pct 379 Speed Reference 146
Trim Torque 40 Torq Attributes 133
TrqTpr Enable 750 Torq Attributes 134
TrqTpr Lim0 751 Torq Attributes 134
TrqTpr Lim1 752 Torq Attributes 134
TrqTpr Lim2 753 Torq Attributes 134
TrqTpr Lim3 754 Torq Attributes 134
TrqTpr Lim4 755 Torq Attributes 134
TrqTpr Spd 756 Torq Attributes 134
TstGen Amplitude 60 Test Generator 142
TstGen Frequency 59 Test Generator 142
TstGen Offset 61 Test Generator 142
TstGen Output 58 Test Generator 142
UnderVlt Flt Dly 470 Alarms 182
UnderVolt Thresh 481 Alarms 182
UserDefined0 503 User Defined 185
UserDefined1 504 User Defined 185
UserDefined10 513 User Defined 185
UserDefined11 514 User Defined 185
UserDefined12 515 User Defined 185
UserDefined13 516 User Defined 185
UserDefined14 517 User Defined 185
UserDefined15 518 User Defined 185
UserDefined2 505 User Defined 185
UserDefined3 506 User Defined 185
UserDefined4 507 User Defined 185
UserDefined5 508 User Defined 185
UserDefined6 509 User Defined 185
UserDefined7 510 User Defined 185
UserDefined8 511 User Defined 185
UserDefined9 512 User Defined 185
UsrDefBitWrdA 519 User Defined 185
UsrDefBitWrdA0 520 User Defined 186
UsrDefBitWrdA1 521 User Defined 186
UsrDefBitWrdA10 530 User Defined 186
UsrDefBitWrdA11 531 User Defined 186
UsrDefBitWrdA12 532 User Defined 186
UsrDefBitWrdA13 533 User Defined 186
UsrDefBitWrdA14 534 User Defined 186
UsrDefBitWrdA15 535 User Defined 186
UsrDefBitWrdA2 522 User Defined 186
UsrDefBitWrdA3 523 User Defined 186
UsrDefBitWrdA4 524 User Defined 186
UsrDefBitWrdA5 525 User Defined 186
UsrDefBitWrdA6 526 User Defined 186
UsrDefBitWrdA7 527 User Defined 186
UsrDefBitWrdA8 528 User Defined 186
UsrDefBitWrdA9 529 User Defined 186
UsrDefBitWrdB 536 User Defined 186
Name No. Group Page
