Chapter 3 Programming and Parameters
Diam Init Filter
1206 Diameter Calc
Diam Preset 0
1164 Diameter Calc
Diam Preset 1
1165 Diameter Calc
Diam Preset 2
1166 Diameter Calc
Diam Preset 3
1167 Diameter Calc
Diam Preset Sel
1168 Diameter Calc
Diam Stdy Delay
1207 Diameter Calc
Diam Threshold
1158 Diameter Calc
Diameter Calc
794 Init Diam Calc
Diameter Calc St
800 Init Diam Calc
Diameter Filter
1162 Diameter Calc
Diameter Reached
1159 Diameter Calc
Diameter Reset
1157 Diameter Calc
Dig In Status
564 Digital Inputs
Dig In Term 1
565 Digital Inputs
Dig In Term 10
574 Digital Inputs
Dig In Term 11
575 Digital Inputs
Dig In Term 12
576 Digital Inputs
Dig In Term 2
566 Digital Inputs
Dig In Term 3
567 Digital Inputs
Dig In Term 4
568 Digital Inputs
Dig In Term 5
569 Digital Inputs
Dig In Term 6
570 Digital Inputs
Dig In Term 7
571 Digital Inputs
Dig In Term 8
572 Digital Inputs
Dig In Term 9
573 Digital Inputs
Dig Out Status
581 Digital Outputs
Digital In1 Sel
133 Digital Inputs
Digital In10 Sel
142 Digital Inputs
Digital In11 Sel
143 Digital Inputs
Digital In12 Sel
144 Digital Inputs
Digital In2 Sel
134 Digital Inputs
Digital In3 Sel
135 Digital Inputs
Digital In4 Sel
136 Digital Inputs
Digital In5 Sel
137 Digital Inputs
Digital In6 Sel
138 Digital Inputs
Digital In7 Sel
139 Digital Inputs
Digital In8 Sel
140 Digital Inputs
Digital In9 Sel
141 Digital Inputs
Digital Out1 Sel
145 Digital Outputs
Digital Out2 Sel
146 Digital Outputs
Digital Out3 Sel
147 Digital Outputs
Digital Out4 Sel
148 Digital Outputs
Digital Out5 Sel
149 Digital Outputs
Digital Out6 Sel
150 Digital Outputs
Digital Out7 Sel
151 Digital Outputs
Digital Out8 Sel
152 Digital Outputs
Direction Mask
594 Masks & Owners
Direction Mode
1322 Reference Config
Direction Owner
603 Masks & Owners
Name
No.
Group
Page
DncrPosSpd
795 Init Diam Calc
DPI Baud Rate
589 Comm Control
DPI Fdbk Select
1321 Comm Control
DPI P1 Select
1323 DPI Inputs
DPI P2 Select
1324 DPI Inputs
DPI P3 Select
1325 DPI Inputs
DPI P4 Select
1326 DPI Inputs
DPI P5 Select
1327 DPI Inputs
DPI Port Sel
590 Comm Control
DPI Port Value
1343 Comm Control
Drive Alarm 1
1380 Alarms
Drive Alarm 2
1394 Alarms
Drive Checksum
332 Drive Data
Drive Logic Rslt
1328 Diagnostics
Drive Size
465 Drive Data
Drive Status 1
381 Diagnostics
Drive Status 2
382 Diagnostics
Drive Type
300 Drive Data
Drive Type Sel
201 Motor Data
Droop Filter
697 Load Limits
Droop Limit
700 Load Limits
Droop Out
1006 Speed Meters
Droop Out Pct
1007 Speed Meters
Droop Percent
696 Load Limits
Drv Fld Brdg Cur
374 Motor Data
Dynamic Friction
1175 Winder
Functions
Elapsed Lifetime
235 Drive Data
Enable Droop
699 Load Limits
Enable PD
770 PD Control
Enable PI
769 PI Control
Enable PI PD
1258 PID Control
Encoder Config
170 Speed Feedback
Encoder Counts
1022 Speed Feedback
Encoder Err Chk
652 Speed Feedback
Encoder Out Sel
1021 Speed Feedback
Encoder PPR
169 Speed Feedback
Encoder Speed
420 Speed Meters
Fast Stop Status
1190 Winder
Functions
Fast Stop Time
38
Stop Modes
Fault 1 Code
1351 Faults
Fault 1 Time
1361 Faults
Fault 10 Code
1360 Faults
Fault 10 Time
1370 Faults
Fault 2 Code
1352 Faults
Fault 2 Time
1362 Faults
Fault 3 Code
1353 Faults
Fault 3 Time
1363 Faults
Fault 4 Code
1354 Faults
Name
No.
Group
Page
Fault 4 Time
1364 Faults
Fault 5 Code
1355 Faults
Fault 5 Time
1365 Faults
Fault 6 Code
1356 Faults
Fault 6 Time
1366 Faults
Fault 7 Code
1357 Faults
Fault 7 Time
1367 Faults
Fault 8 Code
1358 Faults
Fault 8 Time
1368 Faults
Fault 9 Code
1359 Faults
Fault 9 Time
1369 Faults
Fault Arm Amps
1371 Faults
Fault Clear
1347 Faults
Fault Clr Mask
597 Masks & Owners
Fault Clr Mode
1348 Faults
Fault Clr Owner
606 Masks & Owners
Fault Field Amps
1373 Diagnostics
Fault Speed
1372 Diagnostics
Fault Voltage
1374 Diagnostics
FaultCode
57
Drive Data
Fdbk Device Type
414 Speed Feedback
Fdbk Option ID
422 Speed Feedback
Feed Fwd PID
758 PID Control
Feedback Offset
563 Speed Feedback
Field Current
351 Current Meters
Field Curve Out
476 Current Meters
Field Econ Delay
1407 Field Config
Field Economy En
499 Field Config
Field Mode Sel
469 Field Config
Field Reg Enable
497 Field Config
Filt TorqCur Pct
928 Current Meters
Final Diameter
1178 Winder
Functions
Float Tolerance
1111 Torque Prove
Fld Const 40 Pct
916 Field Config
Fld Const 70 Pct
917 Field Config
Fld Const 90 Pct
918 Field Config
Fld Current Pct
234 Current Meters
Fld Reg Ki
92
Field Config
Fld Reg Ki Base
98
Field Config
Fld Reg Kp
91
Field Config
Fld Reg Kp Base
97
Field Config
Fld Test Angle
168 Test Generator
Fld Weaken Ratio
456 Field Config
FldLoss Flt Cfg
473 Alarms
FldLoss Flt Dly
475 Alarms
Flux Divide
462 Field Config
Flux Filter BW
463 Field Config
Flux Ref Pct
500 Current Meters
Flying Start En
388 Speed Regulator
Name
No.
Group
Page
