Rockwell Automation Publication 20P-UM001K-EN-P - July 2014 237
Supplemental Drive Information Appendix A
Frame A and B AC Input Line Fuses
AC input line fuses are externally mounted for frame A and B drives and must be
sourced separately. See Fuse Code FS1 in
Figure 68 on page 236 .
Table 47 - 230V AC Input Drives
Table 48 - 460V AC Input Drives
Fr
am
e
Drive
Current
Rating
Code DC
Amps AC
Line
Amps Bussmann Mersen
Ferrule FWP
Type North American
FWP Type Ferrule A70QS
Type North American
A70P / A70QS Type
A 7P0 7 5.7 FWP-10A14F FWP-10B A70QS10-14F A70P10-4
9P0 9 7.4 FWP-15A14F FWP-15B A70QS16-14F A70P15-4
012 12 9.8 FWP-20A14F FWP-20B A70QS20-14F A70P20-4
020 20 16 FWP-25A14F FWP-25B A70QS25-14F A70P25-4
029 29 24 FWP-40A22F FWP-40B A70QS40-22F A70QS40-4
038 38 31 FWP-63A22F FWP-60B A70QS63-22F A70QS60-4
055 55 45 FWP-80A22F FWP-80B A70QS80-22F A70QS80-4
073 73 60 – FWP-100A – A70QS100-4K
093 93 76 – FWP-150A – A70QS150-4K
110 110 90 – FWP-175A – A70QS175-4K
B 146 146 119 – FWP-250A – A70QS250-4
180 180 147 – FWP-300A – A70QS300-4
218 218 178 – FWP-350A – A70QS350-4
265 265 217 – FWP-400A – A70QS400-4
360 360 294 – FWP-600A – A70QS600-4K
434 434 355 – FWP-600A – A70QS600-4
Fr
am
e
Drive
Current
Rating
Code DC
Amps AC Line
Amps Bussmann Mersen
Ferrule FWP
Type North American
FWP Type Ferrule A70QS
Type North American
A70P / A70QS Type
A 4P1 4.1 3.3 FWP-10A14F FWP-10B A70QS10-14F A70P10-4
6P0 6 4.9 FWP-10A14F FWP-10B A70QS10-14F A70P10-4
010 10 8.2 FWP-20A14F FWP-20B A70QS20-14F A70P25-4
014 14 11.4 FWP-25A14F FWP-25B A70QS25-14F A70P25-4
019 19 15.5 FWP-25A14F FWP-25B A70QS25-14F A70P25-4
027 27 22.1 FWP-40A22F FWP-40B A70QS40-22F A70QS40-4
035 35 28.6 FWP-63A22F FWP-60B A70QS63-22F A70QS60-4
045 45 36.8 FWP-80A22F FWP-80B A70QS80-22F A70QS80-4
052 52 42.5 FWP-80A22F FWP-80B A70QS80-22F A70QS80-4
073 73 59.6 – FWP-100A – A70QS100-4K
086 86 70.3 – FWP-150A – A70QS150-4K
100 100 81.7 – FWP-175A – A70QS175-4K
129 129 105.4 – FWP-175A – A70QS175-4K
B 167 167 136.4 – FWP-300A – A70QS300-4
207 207 169.1 – FWP-350A – A70QS350-4
250 250 204.3 – FWP-400A – A70QS400-4
330 330 269.6 – FWP-600A – A70QS600-4K
412 412 336.6 – FWP-600A – A70QS600-4
