130 Rockwell Automation Publication 20P-UM001K-EN-P - July 2014
Chapter 3 Programming and Parameters
MO
TOR C
ONTROL
Fie
ld Co
nf
ig
91 [Fld Reg Kp]
Proportional gain (K
P
) of the flux regulator expressed as a percentage of Par
97 [Fld Reg Kp Base]. Leave set to the default value for permanent magnet
motor applications.
Default:
Min/Max:
Units:
2.00
0.00 / 100.00
%
Real 97
92 [Fld Reg Ki]
Integral gain (K
I
) of the flux regulator expressed as a percentage of Par 98 [Fld
Reg Ki Base]. Leave set to the default value for permanent magnet motor
applications.
Default:
Min/Max:
Units:
1.00
0.00 / 100.00
%
Real 98
97 [Fld Reg Kp Base]
The proportional gain (K
P0
) of the field current regulator (base value). Leave
set to the default value for permanent magnet motor applications.
Default:
Min/Max:
3276.70
0.10 / 32767.00
Real 91
98 [Fld Reg Ki Base]
Integral gain (K
I0
) of the field current regulator in (base value). Leave set to
the default value for permanent magnet motor applications.
Default:
Min/Max:
3276.70
0.10 / 32767.00
Real 92
456 [Fld Weaken Ratio]
The ratio of Motor Nameplate Base Speed to Par 45 [Max Ref Speed] when
Par 469 [Field Mode Sel] = 1 “Field Weaken”. This value is the percentage of
the maximum application speed when field weakening will begin: “Motor
Base Speed” / Par 45 [Max Ref Speed] x 100. If Par 469 [Field Mode Sel] = 0
“Base Speed”, this parameter must be = 100%. Leave set to the default value
for permanent magnet motor applications. Default:
Min/Max:
Units:
100
0 / 100
%
16-bit
Int 921,
469
462 [Flux Divide]
Selects division by flux for Inertia Compensation or Torque Reference. Leave
set to the default value for permanent magnet motor applications.
Note: Added for firmware version 3.001. Default:
Options:
0 =
0 =
1 =
“Torque Ref”
“Torque Ref”
“Inertia Comp”
16-bit
Int
463 [Flux Filter BW]
Adjustable low pass filter on the value of Par 500 [Flux Ref Pct]. The filtered
result is used by the Torque Reference divide by flux function. Leave set to the
default value for permanent magnet motor applications.
Note: Added for firmware version 3.001. Default:
Min/Max:
Units:
50
0 / 2000
ms
16-bit
Int
467 [Max Fld Flux Pct]
Maximum allowable field flux. The maximum value (100%) corresponds to
the value set in Par 280 [Nom Mtr Fld Amps]. The value of this field linearly
affects the field current, unless a flux curve is set in Pars 916, 917, and 918
[Fld Const xx Pct]. Leave set to the default value for permanent magnet
motor applications.
Note: This parameter can be assigned to an analog input or output. Default:
Min/Max:
Units:
100
Par 468 [Min Fld Curr Pct] / 100
%
16-bit
Int 468
Fil
e
Gr
oup
No
. Parameter Name & Description
See page 114 for symbol descriptions
Values Da
ta
T
yp
e
Rela
ted
A
A
A
A
A
A
ATTENTION: Failure to set this parameter to a value appropriate for the intended application could result in excessive
motor speed, equipment damage, and/or bodily injury.
