Apple Shake 4 Tutorials - Manual (Page 159)

Tutorial 4 Working With Expressions 159
• Set xAngle to –7.5.
• Set yAngle to –25.
• Set zAngle to –195.
• Leave center (x, y) at 80.
The result looks similar to this:
To animate the X element:
1 In the Move3D parameters, click the zAngle Autokey button to set a keyframe.
2 Go to frame 5.
3 Set the zAngle parameter to –122.
4 Use the Left Arrow and Right Arrow keys to step through the animation.
The animation matches between frames 1 and 5, but stops at frame 5. Use the Curve
Editor to correct the problem.
Note: When Autokey is enabled, the Load Curve button is activated, so the zAngle
curve is already loaded into the Curve Editor.
5 Click the Curve Editor tab.
6 To select the curve, drag across the curve or select the curve in the curve list.
7 In the Curve Editor, change the curve Cycle mode from KeepValue (default) to
KeepSlope.
