9.23 Model 6036 Legacy
Electrical System
Check 40-amp main fuse.
Check that transmission gear
select lever is in (N) NEUTRAL.
Engine will not crank or
starter solenoid does
not engage.
Repair or replace
connections or cable.
Check that park brake
switch is engaged.
If OK
If OK
Not
OK
Check battery for proper
charge and that connections
are clean and tight.
Check for battery voltage at
starter positive (+) battery
post (RED cable). Check
negative (-) cables for proper
ground and that they are
clean and tight.
With key switch in START
position, check starter
solenoid terminal, wire 106
(BLU/ORG) connection for
battery voltage.
Replace starter.
If OK
If OK
Check circuit 106 (BLU/
ORG) for open or short to
neutral start relay.
Not
OK
Check neutral start relay for
battery voltage at
wire 111 (RED) and 112A
(GRY).
Replace neutral
start relay.
If OK
If OK
If OK
Before troubleshooting any
electrical circuit, ALWAYS
begin by checking the
following:
1. All connections relating
to circuit are clean and
tight.
If OK
Not
OK
Not
OK
Check 111 (RED) at park
brake switch and wire 112
(GRY) at transmission shifter
connector with shifter in (N)
NEUTRAL position. If 112
(GRY) Not OK, check for
battery voltage on wire 153
(GRY/WHT) to shifter. If OK,
replace shifter.
Not
OK
Check voltage on wire 1
(WHT) in START mode to
park brake switch.
Disconnect ignition switch
harness connector from cab
harness and on the cab
harness side check wire 3C
(PUR) for battery voltage.
Replace ignition switch.
Not
OK
