Electrical system – SkyTrak 6036 Service Manual User Manual
Page 371
9.19
Model 6036 Legacy
Electrical System
2
14
BLU
Front Wiper Switch to Front Wiper Motor (HIGH) Conn.
3
14
WHT
Front Wiper Switch to Front Wiper Motor (LOW) Conn.
4A
14
GRN
Front Wiper Motor (PARK) to Front Wiper Switch
5
14
YEL
Roof Wiper Switch to Roof Wiper Motor Conn.
6
14
RED/WHT
Cab Harness Conn. 6F to Front Wiper Switch
6A
14
RED/WHT
Front Wiper Switch (POWER) to Front Wiper Switch Jumper Pin Conn.
6B
14
RED/WHT
Cab Harness Conn. 6F to Roof Wiper Switch
6C
14
RED/WHT
Roof Wiper Switch (POWER) 6B to Roof Wiper Switch Jumper Pin Conn.
6D
14
RED/WHT
Washer Harness Conn. 6F to Washer Switch
6E
14
RED/WHT
Washer Switch (POWER) 6D to Washer Switch Jumper Pin Conn.
7
14
PUR
Front Wiper Switch (Pin 4) to Front Wiper Switch Jumper (Pin 2)
8
14
PUR
Roof Wiper Switch (Pin 4) to Roof Wiper Switch Jumper (Pin 2)
9
14
GRN
Roof Wiper Switch to Roof Wiper Motor
10
14
GRN
Washer Switch to Washer Motor
HEATER HARNESS WIRES (OPTION)
1
14
YEL
Heater Switch to Heater Fan Motor (LOW)
2
14
RED/WHT
Cab Harness Conn. to Heater Switch
3
14
ORG
Heater Switch to Heater Fan Motor (HIGH)
4
14
RED
Heater Switch to Heater Fan Motor (MEDIUM)
5
14
BLK
Cab Harness Ground to Heater Motor
Wire No.
Gauge
Color
From
Function
To
