9.15
Model 6036 Legacy
Electrical System
9.7.5
Electrical Schematic Legend (6036)
Wire No.
Gauge
Color
From
Function
To
1
10
WHT
Ignition to Park Brake Switch
2
14
BLK
Horn Button to Ground
2A
18
BLK
Splice 20 to Fuel Sender
2B
16
BLK
Splice 20 to Steer Select Valve
2C
16
BLK
Splice 20 to Steer Select Valve
2D
16
BLK
Diode Pack to Splice 20 (Ground)
2G
16
BLK
Splice 20 (Ground) to Transmission Ground
2H
18
BLK
Splice 20 (Ground) to Lower Transmission Connector (Pin 7)
2J
18
BLK
Splice 20 (Ground) to Upper Transmission Connector (Pin 7)
2K
16
BLK
(Not Used)
2K1
16
BLK
Secondary Function Manifold to Splice 20 (Ground)
2K2
16
BLK
Secondary Function Manifold to Splice 20 (Ground)
2L
16
BLK
(Not Used)
2M
16
BLK
(Not Used)
2N
16
BLK
(Not Used)
2P
16
BLK
(Not Used)
2R
18
BLK
(Not Used)
2S
16
BLK
Splice 20 (Ground) to Fuel Shut-off Solenoid
2T
16
BLK
(Not Used)
2W
16
BLK
Splice 20 (Ground) to Alternator
2X
16
BLK
Splice 20 (Ground) to Back-up Alarm
2AA
18
BLK
(Not Used)
2BB
18
BLK
Splice 20 (Ground) to Back-up Alarm Relay
2CC
18
BLK
(Not Used)
2EE
18
BLK
Splice 20 (Ground) to Park Brake Disconnect Relay
2FF
18
BLK
Splice 20 (Ground) to Neutral Start Relay
2GG
16
BLK
Splice 20 (Ground) to Instrument Cluster
2KK
18
BLK
Splice 20 (Ground) to Light Switch Relay
3
14
RED
Power Bar
3A
10
PUR
Power Bar to Transmission Fuse
3B
14
RED
Fuse Power
3C
14
PUR
Ignition to Fuse Power Feed
5
10
RED
Starter to Alternator (“B+” Terminal)
6
18
YEL
Instrument Panel to Cab/Chassis Connector to Alternator (“D+” Terminal)
7
16
BRN
(Not Used)
8
16
LT GRN/WHT
Steer Select Switch to Cab/Chassis to Steer Select Valve (Crab)
9
16
GRN/BLK
Steer Select Switch to Cab/Chassis to Steer Select Valve (4-Wheel)
10
16
TAN
(Not Used)
11A
16
LT GRN
Fuse to Steer Select Switch
11B
16
LT GRN
Steer Select Switch Connector (Pin 2) to Pin 8
