2.15 Model 6036 Legacy
General Information and Specifications
2.5.9 Hydraulic System
2.5.10 Tires
2.5.11 Miscellaneous Specifications
Valve Relief Settings (46 GPM Bench Flow):
Main Valve Clipping Relief 3,500 ±100 psi (241,5 bar)
Main Pump Standby Pressure at Pump Outlet 250-300 psi (17-21 bar)
Main Relief Pressure at Unloader Valve "VG" Test Port 2500-3100 psi (172-214 bar)
Parking Brake Relief 650-700 psi (45-48 bar)
Port Relief Boom - Hoist 3,250 ±100 psi (224 ±7 bar)
Port Relief Boom - Extend (Both Sides) 3,250 ±100 psi (224 ±7 bar)
Port Relief Fork Tilt (Both Sides) 3,250 ±100 psi (224 ±7 bar)
Port Relief AUX (Optional) 3,250 ±100 psi (224 ±7 bar)
Parking Brake Pressure Reducing Valve 500-600 psi (34-41 bar)
Steering Pressure Reducing Valve 2,500 ±100 psi (172 ±5 bar)
Tire Size 13.00-24, 12-ply
Wheel Lug Nut Torque 450 lb/ft (610 Nm)
Air Pressure 55 psi (379 kPa)
Tire Footprint Area (area is established under maximum tip load):
Vehicle with Rated Load
150 in
2
(968 cm
2
)
Maximum Ground Pressure
(maximum ground pressure at tip = (machine weight + load) / (2 x footprint area):
Vehicle with Rated Load 87 psi (600 kPa)
Steering Wheel:
Maximum Number of Turns, Lock to Lock 3.75 turns
Minimum Number of Turns, Lock to Lock 3.00 turns
Breakout Force:
Utility bucket
(calculated at -24° lip angle, maximum moment) 24,500 lb (11.113 kg)
