41
CSGX Ceramic grooving inserts
Fits in RCGX/RPGX ‘V bottom’ holders.
CSGX 060608 T01020 670,
width 6.35 mm
CSGX 090708 T01020 670,
width 9.75 mm
CSGX 120708 T01020 670,
width 12.7 mm
High metal removal – effective use in:
• Machining into corner after square insert
• Wide grooving – use turret method
Seal-fin
Special tool holder for standard inserts.
440 310211R44 right hand
440 310211L45 left hand
• Optimized for good stability and accuracy
profiling cuts
• High pressure nozzle
• Good chip control
• Depth of cut (a
r
) 8 mm
N123E2-0200-RO
width 2.0 mm
GC S05F – first choice for HRSA
