Cmc 20.22, Component/feature solutions – Sandvik Coromant Heat resistant super alloys User Manual

Page 118

background image

116

C

B

A

CMC 20.22

D

Component/feature solutions

Casing

Ø 60 mm

Ø 22

mm

20

mm

5 mm

Ø 8.00 mm

15 mm

5/16-24 UNF

Waspalloy
