HP XP RAID Manager Software - Manual (Page 65)

Using RAID Manager 65
Status Pairing Status Primary Secondary
SMPL Unpaired (SnapShot) volume R/W enabled R/W disabled
(Note 2)
PAIR
(PFUL)
The snapshot available state allocated the resource. R/W enabled R/W disabled
COPY The preparing state allocates the resource for the
snapshot. R/W enabled R/W disabled
RCOPY The copying state from snapshot to the primary
volume by using restore option. R/W disabled R/W disabled
PSUS
(PFUS)
The differences of the updated data of the primary
and secondary volume are controlled with copying
on write. R/W enabled R/W enabled
PSUE
(Error)
"PSUS" status owing to an internal failure. The
differences of the updated data for the snapshot
volume are not controlled. R/W enabled
(Note 1)
R/W disabled
Note 1: Valid when reading and writing are enabled, as long as no failure occurs in the P-VOL.
Note 2: A V-VOL unmapped to the SVOL of SnapShot will reply to a SCSI Inquiry, but is not
enabled for Reading and/or Writing.
