Configuration file examples 285
Cascading connection configuration files
The following are examples of configuration files and the corresponding
(pairdisplay) outputs.
Cascading BC
You should use two configuration files to describe a cascaded (tiered) BC
configuration, as shown in the preceding figure.
No MU designations in configuration file MU#0 BC SnapShot BC only
CA BC MU #1-2
(MU#3-63)
MU#1 MU#2
1 HORCM_DEV
#dev_group dev_name port# TargetID LU# MU#
Oradb oradev1 CL1-D 2 1
oradev1 oradev1
2 HORCM_DEV
#dev_group dev_name port# TargetID LU# MU#
Oradb oradev1 CL1-D 2 1
Oradb1 oradev11 CL1-D 2 1 1
Oradb2 oradev21 CL1-D 2 1 2
oradev1 oradev1 oradev11
oradev21
oradev11
oradev21
3 HORCM_DEV
#dev_group dev_name port# TargetID LU# MU#
Oradb oradev1 CL1-D 2 1
Oradb1 oradev11 CL1-D 2 1 0
Oradb2 oradev21 CL1-D 2 1 1
Oradb3 oradev31 CL1-D 2 1 2
oradev1
oradev1
1
oradev21
oradev31
oradev21
oradev31
4 HORCM_DEV
#dev_group dev_name port# TargetID LU# MU#
Oradb oradev1 CL1-D 2 1 0
oradev1
5 HORCM_DEV
#dev_group dev_name port# TargetID LU# MU#
Oradb oradev1 CL1-D 2 1 0
Oradb1 oradev11 CL1-D 2 1 1
Oradb2 oradev21 CL1-D 2 1 2
oradev1
oradev11
oradev21
oradev11
oradev21
6 HORCM_DEV
#dev_group dev_name port# TargetID LU# MU#
Oradb oradev1 CL1-D 2 1
Oradb1 oradev11 CL1-D 2 1 0
Oradb2 oradev21 CL1-D 2 1 h1
Oradb3 oradev31 CL1-D 2 1 h2
Oradb4 oradev41 CL1-D 2 1 h3
oradev1 oradev1
1
