RAID Manager command reference

127

LK

Indicates the results of a check on the paired volume
connection path.

PORT

Displays the disk array port number.

C/B/12

Corresponds to CA volume/BC volume/BC MU#1,2.
Displays attributes where:

P = P-VOL

S = S-VOL

s = SMPL

R:Group

Displays the physical position of an LDEV as
determined by LDEV mapping in the disk array.

PRODUCT_ID

Displays the product ID field in the STD inquiry page.

PWWN

Displays the port WWN.

NWWN

Displays the Node WWN.

AL

(Not supported for the Tru64 or Digital UNIX
–CLIWP

and –CLIWN options) Displays the AL_PA

of the port.

Examples

LDEV Mapping

R:

Group

RAID group

RAID Level

1 = RAID1

5 = RAID5

6 = RAID6

RAID Group number - Sub number

SnapShot S-VOL

S

SNAPS

Pool ID number

Pool ID number

Unmapped

U

UNMAP

00000

Group 00000

External LUN

E

External Group number
